Dual-Centrifugal Fans
Move air quietly and efficiently — up to 400 cu. ft. of air per minute.
Halogen Lighting
For bright illumination of the cooktop surface.
Washable Filters
Dishwasher safe for easy cleaning. The aluminum filter provides strength and durability not found in foam filters.
| General Specifications | |
|---|---|
| Filter Type | Dishwasher-Safe |
| Product Weight (lbs) | 78 |
| Power Type | Electric |
| Size | 30'' |
| Installation Type | Wall Mounted |
| Collection | Frigidaire |
| ELECTRICAL SPECIFICATIONS | |
| Amps @ 120 Volts | 4.0 |
| Circuit Amps | 15.0 |
| Connected Load (kW Rating) @ 120V | 0.516 |
| Voltage Rating | 120V 60Hz |
| Watts @ 120 Volts | 520 |
| Certifications & Approvals | |
| Agency Approval | UL/cUL |
| UL/cUL Approval | Yes - cULus |
| Vent & Light System | |
| Blower Type | Centrifugal |
| Duct Diametre | 6" |
| Ducted / Ductless Vent Installation | Yes |
| Exhaust Duct | Convertible |
| Exhaust Fan Capacity (CFM) | 400 |
| Exhaust Fan Speeds | 3 |
| Filters | 2 |
| Lights | 2 |
| Sones Rating | 3.63 to 7.94 (1 to 3 speeds) |
| Sound Level (dBA) | 58.5 to 69.9 (1 to 3 speeds) |
| Work-Area Light | Halogen Lighting |
| CONTROLS | |
| Control Buttons | 5 |
| Electronic Controls with LCD Display | No |
| Accessories | |
| Recirculation Kit for Wall-Mount Hoods | Stainless - Optional order item no. FHWRKT55LS |
| Wall-Mount Extended Kit | Stainless - Optional order item no. FHW10X55LS |
| Exterior Dimensions | |
| Depth | 19-11/16" |
| Height (Min.) | 31-11/16" |
| Height (with Flue Extension) | 45" |
| Width | 29-7/8" |
