30" Sirius Pro-Style Wall Mount Chimney Hood with 600 CFM - SU5430X
| Accessories | |
|---|---|
| Charcoal filters: | KF2 (Order 1 pc for 30” version and 2 pcs for 48” version) Cod. 60071099999 |
| Flue Extension: | Lower chimney extension h= 35”7/16 for a min/max height of 53”5/32 - 64”31/32 cod. 20001154886 |
| Air deviator: | Def S51 75005100105 |
| SPECIFICATION RANGES | |
| Discharge: | Vertical |
| Air Outlet: | 6” round for SU54 30” |
| Grease Filter: | Commercial style baffle filters |
| Control Panel: | Chromed 4 speed push-button + delay off timer + light switch |
| Lighting: | Led spot 2X2,1W in 30” version |
| Motor: | |
| Noise level: | 66 dBA/5.1 sones |
| Pressure: | 800 Pa |
| One motor: | EBM 600 cfm for SU54 30” version |
