Platinum Star Limited Warranty
Our exclusive limited warranty that includes 3-year coverage on parts and one year on labor.1
Large Capacity
Stores up to 30 pounds of ice cubesand makes over 34 pounds of ice in a 24-hour period.
Crystal-Clear Ice Cubes
Makes crystal-clear ice perfect for entertaining.
Factory Installed Drain Pump
This icemaker is easy to install, unlike some that require installation of a separate accessory drain pump kit
Low Maintenance
Has a cleaning mode and self-defrosts.
Integrated Controls
Controls are on the top of the door so they're easy to set when needed, and hidden from view when the door is closed.
Versatile Installation Options
Can be used freestanding or under-counter.
Left Hinge door
Select the perfect factory installed door swing for your installation.
Energy-saving eco mode
Slows ice production and saves approximately 23% of water and electric usage.
Delay Mode
Suspends ice production for 2, 4, 6, or 8 hours or days. Perfect during sleeping hours, or during the week for your weekend vacation home.
CERTIFICATIONS & APPROVALS | |
---|---|
ADA Compliant | Yes |
CSA Certified | Yes |
ENERGY STAR® Certified | No |
CONTROLS | |
Control Buttons | 4 |
Eco Mode | Yes |
Control Location | Top of door |
Control Lock | Yes |
Control Panel | Touch |
Controls | IQ-TouchTM |
Power On/Off Control | Yes |
Controlx | |
Delay Mode | Yes |
Control Type Color | |
Controls | Smooth Black |
Exterior Dimensions | |
Case Height | 33-3/4" |
Case Width | 14-15/16" |
Case Depth | 21-1/2" |
Depth | 23-5/8" |
Depth (with Door 90° Open) | 37-13/22" |
Depth with Doors and Handles | 26-1/8" |
Height | 34-3/4" |
Height (Min.) | 33-3/4" |
Width | 14-7/8" |
Cut-Out Dimensions | |
Cut-Out Width | 15-1/8" |
EXTERIOR SPECIFICATIONS | |
Cabinet Color | Black |
Door Closers | Yes |
Door Gasket | Black |
Door Stops | Yes |
Door Swing Type | Under-Counter Left-Swing |
Reversible Door | No |
Toe Grille | Stainless Steel |
Door Finish | |
Exterior Specifications | Stainless Steel |
General Specifications | |
Frost-Free Performance | Yes |
Condenser Type | Dynamic |
Adjustable Leveling Legs | 4 |
Water Inlet Location | Left Rear Bottom |
Product Weight (lbs) | 100 |
Shipping Weight (lbs) | 105 |
Vacation Mode | Yes |
Ice Maker | |
Daily Ice Production | Up to 34 Lbs. |
Ice Cube Type | Clear |
Ice Cube Size | 7/8" |
Ice Cubes Produced per Cycle | 130 |
Self-Cleaning Process Steps | 3 |
Self-Cleaning of Mineral Deposits | Yes |
ELECTRICAL SPECIFICATIONS | |
Power Supply Connection Location | Left Rear Bottom |
Voltage Rating | 120V 60Hz |
Connected Load (kW Rating) @ 120V | 0.48 |
Minimum Circuit Required (Amps) | 15A |
Power Cord Length | 72" |
Accessories | |
Ice Scoop | Included |
Cleaning Kit | Optional order item no. EIM41978 |
Handle Kit | Optional order item no. 5304503432 |
